TG18 is Network Biometric Access Control System . with high steady and strong access control functions together. With the top algorithm to make sure the identification speed and rates, suits all company and buildings.
Products Features:
- Multiple identification: fingerprint and card together.
- Touch Key
- 500 Dip hidden fingerprint sensor for dry fingerprint and strong sunshine.
- Wiegand In & Out to combine with access controller.
- Standard TCP/IP, RS485, USB for communication with computer and server together.
- With software management together for time attendance and access control.
- Lighted keypad for easier operation and using at night.
- Free SDK and Free software
- Two door interlock function: A door open, B door closed.
Product Specification
| Model | TG18(Network Biometric Access Control System) |
| Working | Standalone or Network |
| Identification Style | Fingerprint/Card/Password |
| Identification Speed | <1 sec |
| FAR | <0.01 |
| FAR | <0.0001 |
| Fingerprint Capacity | 3000 |
| Card Capacity | 3000 |
| Display | 2.0 TFT Color LCD |
| Language | English/Spanish/Turkish/Arabic/Thai/French and so on |
| Communication | WAN remote/RS485/TCP/IP/USB/Wifi |
| Humidity | 20%-60% |
| Temperature | 0℃-40℃ |
| Time Zone and Groups | 8 time zones and 8 time groups, 5 combinations |
| Wiegand out | Wiegand 26&34 |
| Input | Door sensor, exit button |
| Output | Electric Lock |
| Alarm | Defend, Unlock and Threaten |
| Voice | Boom, Dual LED |
| Power Supply | DC12V |
| Anti-pushback | In & out door |
| Size | 190*80*33mm |
| Other Functions | Mifare/WiFi |
Downloard Datasheet TG-18W
